Fluke Tested Lan UTP Patch Cord Cable Cat5e Full Copper Snagless Mold Injection Type

Product Categories
SHENZHEN BLG DIGITAL NETWORK CO., LIMITED
Contact Now

Fluke Tested Lan UTP Patch Cord Cable Cat5e Full Copper Snagless Mold Injection Type

Brand Name : BLG / OEM / ODM

Model Number : UTP PATCH CORD

Certification : CE / ROHS / ISO

Place of Origin : CHINA

MOQ : 1000 Pieces

Price : Negotiable

Payment Terms : T/T, Western Union, L/C

Supply Ability : 10000 Pieces / Week

Delivery Time : 10 - 15 Work Days

Packaging Details : 1 Piece / PE Bag, 200 Pieces / Carton or Customized

Item : Cat5e Patch Cable

Conductor : Full Copper

Connectors : UTP 8P8C RJ45 Male Plug

Mold Injection : Snagless

Color : Grey, White, Blue, Yellow or Others

Package : 1PCS / PE Bag or Customized

Contact Now

Fluke Tested Lan Patch Cord Cable UTP Cat5e Full Copper with Snagless Mold Injection Type

COMPLIANCE WITH

  • ISO / IEC 11801
  • TIA / EIA - 568 - B. 2
  • IEC - 60332 - 1
  • RoHS
  • CE

CONSTRUCTION

  • Conductor: 24AWG Full Copper
  • Insulation: HDPE
  • Cabling: 568B
  • Jacket: PVC
  • Connectors: 2 * 8P8C RJ45 Male Plugs

ELECTRICAL PROPERTIES
Conductor Resistance Max. 138 ohms/km at 20°C
Insulation Resistance Min. 5000 mega ohms-km at 20°C
Dielectric Test 1000V DC /1 min ; No Breakdown
Temperature Rating 75°C
Voltage Rating 30V
Frequency
(MHZ)		 Zin - OS
(Ohm)		 Fitted Z
(Ohm)		 SRL
(dB)		 ATT(PATCH)
(dB / 100M)		 DELAY
(ns / 100M)		 MAX. DELAY SKEW (ns / 100M) NEXT
(dB)		 PS NEXT
(dB)
0.772 100 ± 15 100 ± 15 19.40 1.8 574.97 45.0 67 64
1 20.00 2 570 45.0 65.3 62.31
4 23.00 4.1 552.00 45.0 56.3 53.28
8 24.50 5.8 546.73 45.0 51.8 48.77
10 25.00 6.5 545.38 45.0 50.3 47.31
16 25.00 8.2 543.00 45.0 47.3 44.25
20 25.00 9.3 542.05 45.0 45.8 42.8
25 24.30 10.4 541.20 45.0 44.3 41.35
31.25 23.60 11.7 540.44 45.0 42.9 39.89
62.5 21.50 17 538.55 45.0 38.4 35.38
100 20.10 22 537.60 45.0 35.3 32.31

COLOR CODE

  • Pair1: Orange / White Orange
  • Pair2: Blue / White Blue
  • Pair3: Green / White Green
  • Pair4: Brown / White Brown


Color: Optional ( White, Red, Blue, Black, Yellow... )

Length: Optional ( 0.5m, 1m, 2m, 3m... )

Certification: CE, RoHS Compliant

APPLICATION

  • 100 Base-T4
  • 100 Base-TX
  • 100VG-AnyLAN
  • 1000 Base-T(Gigabit Ethernet)
  • 155 Mbps ATM
  • 622 Mbps ATM

Fluke Tested Lan UTP Patch Cord Cable Cat5e Full Copper Snagless Mold Injection TypeFluke Tested Lan UTP Patch Cord Cable Cat5e Full Copper Snagless Mold Injection Type
